AsRock Rack 1U4LW-B650/2L2T 1U Rackmount General Purpose/Storage Server Barebone Single Socket AM5 (LGA 1718) supports AMD EPYC™ 4004 and AMD Ryzen™ - Pappy Mall

Click to enlarge

AsRock Rack 1U4LW-B650/2L2T 1U Rackmount General Purpose/Storage Server Barebone Single Socket AM5 (LGA 1718) supports AMD EPYC™ 4004 and AMD Ryzen™ – Pappy Mall

Name: AsRock Rack 1U4LW-B650/2L2T 1U Rackmount General Purpose/Storage Server Barebone Single Socket AM5 (LGA 1718) supports AMD EPYC™ 4004 and AMD Ryzen™ - Pappy Mall
SKU: 0262247A
Availability: InStock

SKU: 0262247A

$1,257.54

Add to wishlist

Add to compare

18 People watching this product now!

Fast Shipping

Carrier information

20k products

Payment methods

24/7 Support

Unlimited help desk

2-day Delivery

Track or off orders

Additional information

ryzen-7-pro	7745(100-000000599)
ryzen-7	7700X(100-000000591)
ryzen-9	7950X3D(100-000000908)
ryzen-5-pro	7645(100-000000600)
ryzen-9-pro	7945(100-000000598)
ryzen-5	7600X(100-000000593)
hynix-hmcg78agbua081n	16GB DDR5 5600 non-ECC
micron-mtc10c1084s1ec52baz	16GB DDR5 5200 ECC
crucial-ct32g48c40u5-m16a1	32GB DDR5 4800 non-ECC
hynix-hmcg88aebea084n	32GB DDR5 4800 ECC
kingston-ksm48e40bd8km-32hm	32GB DDR5 4800 ECC
samsung-m323r4ga3bb0-cqk0d	32GB DDR5 4800 non-ECC
smart-sr4g7ud5285-sb	32GB DDR5 4800 ECC
crucial-ct32g52c42u5-m16g1	32GB DDR5 5200 non-ECC
smart-sr6g7ud5385mb01	48GB DDR5 4800 ECC
hynix-hmcg88aebua081n	32GB DDR5 4800 non-ECC
kingston-kvr48u40bd8-32	32GB DDR5 4800 non-ECC
micron-mtc20c2085s1ec48ba1	32GB DDR5 4800 ECC
samsung-m324r4ga3bb0-cqk0l	32GB DDR5 4800 ECC
crucial-ct16g48c40u5-m8a1	16GB DDR5 4800 non-ECC
best-seller-ranking	#12 in Server Barebones
brand	ASRock Rack
model	1U4LW-B650/2L2T
form-factor	1U Rackmount
workload	General Purpose Server
cpu-type	AMD Ryzen 7000 Series
cpu-socket	Single Socket AM5 (LGA 1718)
installed-cpu	No CPU Installed
max-processors	1
north-bridge	AMD B650
memory-slots	4 DIMM slots (2DPC)DDR5 288-pin ECC/non-ECC UDIMM
installed-memory-size	No Memory Installed
max-memory-supported	Max. Capacity per DIMM: 48GB
memory-type-supported	Max. DIMM Frequency: 5200 MHz (1DPC) , 3600 MHz (2DPC)
ecc-supported	Yes
installed-hdd	No Storage Installed
serial-ata	4 x SATA 600
m-2	1 M-key (PCIe5.0 x4) , supports 2280/2242 form factor [CPU]
gpu-vpu	Aspeed AST2600
pci-express	Rear: 1 FH PCIe4.0 x16 via RB1UX16_G4
first-lan	Broadcom BCM57416: 2 RJ45 (10GbE)
second-lan	Intel i210: 2 RJ45 (1GbE)
max-lan-speed	10 Gigabit
hot-swap-bays	4 Hot-swap 3.5" SATA drive bays
front-usb	2 Type-A (USB3.2 Gen1)
other-ports	UID Button/LED: 1 UID button w , LEDVGA Port: 1 DB15 (VGA) , 1 DisplayPort , 1 HDMISerial Port: 1 DB9 (COM)USB 3.2 Gen1 Port: 4 Type-A (USB3.2 Gen1)RJ45: 2 RJ45 (10GbE) , 2 RJ45 (1GbE) , 1 dedicated IPMI
max-power	400W 80-PLUS Gold
system-compatibility	Microsoft Windows:- Windows 10 (64 bit)- Windows 11 (64 bit)Linux:- RedHat Enterprise Linux Server 8.7 (64bit)- CentOs 8.5 ( 64 bit)- SUSE SLES 15.4(64 bit) , 15.2(64 bit)- UBuntu 22.04.1 (64 bit) , 21.10 (64 bit) , 21.04 (64 bit)Hypervisor:- VMWare ESXi 8.0 , 7.0 U3g
bios-features	BIOS Type: AMI UEFI BIOS , 256Mb (32MB) SPI Flash ROMBIOS Features: Plug and Play , ACPI 6.4 compliance wake up events , SMBIOS 3.5
fans	5 PWM Hot-swap 40×28 mm fans
hardware-monitor	Temperature: CPU , DDR , MB , Card Side , Chipset , 10G LAN , M.2 slotFan: Fan Tachometer , Multi-Speed Control , CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)Voltage: VOLT_3VSB , VOLT_5VSB , VOLT_P0_VCORE , VOLT_P0_VSOC , VOLT _VMEM , VOLT _VMISC , VOLT_1.8V_PT21 , VOLT_VSUS10 , VOLT_VDD10 , VOLT_V10_PHY_DIG , VOLT_VDD_1P8 , VOLT_MD_VDDO , VOLT_BAT , VOLT_3V , VOLT_5V , VOLT_12V
temperature	Operation temperature: 10°C ~ 35°C , Non operation temperature: -40°C ~ 70°C
humidity	Non operation humidity: 20% ~ 90% ( Non condensing)
first-listed-on-newegg	April 17 , 2023

Reviews (0)

Rated 0 out of 5

0 reviews

Rated 5 out of 5

0

Rated 4 out of 5

0

Rated 3 out of 5

0

Rated 2 out of 5

0

Rated 1 out of 5

0

Reviews

Clear filters

There are no reviews yet.

Be the first to review “AsRock Rack 1U4LW-B650/2L2T 1U Rackmount General Purpose/Storage Server Barebone Single Socket AM5 (LGA 1718) supports AMD EPYC™ 4004 and AMD Ryzen™ – Pappy Mall”

Description

@import url(//c1.neweggimages.com/WebResource/Themes/WWW/CSS/seller/a_plus_content.css) @import url(//c1.neweggimages.com/WebResource/Themes/WWW/CSS/seller/a_plus_content_responsive.css) CPU SUPPORT LIST Ryzen 7 7800X3D(100-000000910) Ryzen 9 7950X(100-000000514) Ryzen 9 7900(100-000000590) Ryzen 7 7700(100-000000592) Ryzen 5 7600(100-000001015) Ryzen 7 PRO 7745(100-000000599) Ryzen 5 7500F(100-000000597) Ryzen 9 7900X3D(100-000000909) Ryzen 9 7900X(100-000000589) Ryzen 7 7700X(100-000000591) Ryzen 9 7950X3D(100-000000908) Ryzen 5 PRO 7645(100-000000600) Ryzen 9 PRO 7945(100-000000598) Ryzen 5 7600X(100-000000593) MEMORY QVL Hynix HMCG78AGBUA081N 16GB DDR5 5600 non-ECC Micron MTC10C1084S1EC52BAZ 16GB DDR5 5200 ECC Crucial CT32G48C40U5.M16A1 32GB DDR5 4800 non-ECC Hynix HMCG88AEBEA084N 32GB DDR5 4800 ECC Kingston KSM48E40BD8KM-32HM 32GB DDR5 4800 ECC Samsung M323R4GA3BB0-CQK0D 32GB DDR5 4800 non-ECC SMART SR4G7UD5285-SB 32GB DDR5 4800 ECC Crucial CT32G52C42U5.M16G1 32GB DDR5 5200 non-ECC SMART SR6G7UD5385MB01 48GB DDR5 4800 ECC Hynix HMCG88AEBUA081N 32GB DDR5 4800 non-ECC Kingston KVR48U40BD8-32 32GB DDR5 4800 non-ECC Micron MTC20C2085S1EC48BA1 32GB DDR5 4800 ECC Samsung M324R4GA3BB0-CQK0L 32GB DDR5 4800 ECC Crucial CT16G48C40U5.M8A1 16GB DDR5 4800 non-ECC
