Gigabyte MW83-RP0 Intel® Xeon® W Workstation Board, Single processor, LGA 4677, Intel® W790 Chipset, 8-Channel DDR5 RDIMM/3DS-RDIMM, 8 x DIMMs, – Pappy Mall
Original price was: $1,025.74.$950.55Current price is: $950.55.
Fast Shipping
Carrier information
20k products
Payment methods
24/7 Support
Unlimited help desk
2-day Delivery
Track or off orders
| best-seller-ranking |
#52 in Server Motherboards |
|---|---|
| brand |
GIGABYTE |
| model |
MW83-RP0 |
| cpu-socket-type |
LGA 4677 |
| cpu-type |
Supports Intel Xeon W-3500 ,W-2500* ,W-3400 ,W-2400* Processors |
| number-of-processor-support |
1 |
| cpu-features |
Single processor ,TDP up to 385W*Carriers for Intel Xeon W-2500/2400 Processors are not included. Please refer to the optional parts for proper support.Notice: Please select Intel Xeon W-3500/3400 Processors to enable all functions. |
| north-bridge |
Intel W790 |
| memory-slots |
8 x DDR5 288-pin |
| memory-standard |
DDR5 4800 |
| maximum-memory-supported |
2TB |
| channel-supported |
Eight Channel |
| registered |
Yes |
| pci-express-5-0-x16 |
Slot_7: PCIe x16 (Gen5 x16) slot ,from CPUSlot_6: PCIe x16 (Gen5 x16) slot ,from CPU*Slot_5: PCIe x16 (Gen5 x16) slot ,from CPU*Slot_4: PCIe x16 (Gen5 x16) slot ,from CPU*Slot_3: PCIe x16 (Gen4 x16) slot ,from CPUSlot_2: PCIe x16 (Gen5 x16) slot ,from CPUSlot_1: PCIe x16 (Gen4 x16) slot ,from CPU*Slot_4/5/6 are not supported with Intel Xeon W-2500/2400 Processors. |
| sata-raid |
0/1/10/5 |
| sas |
2 x SlimSAS connectors for 8 x SATA 6Gb/s |
| m-2 |
2 x M.2 slots:- M-key- PCIe Gen4 x4 ,from PCH- Support 2280 cards |
| onboard-video-chipset |
Aspeed AST2600 |
| lan-chipset |
Intel X710-AT2 |
| lan-speed |
10Gbps |
| max-lan-speed |
2 x 10Gbps |
| back-i-o-ports |
1 x USB 3.2 Gen2x2 (Type-C)3 x USB 3.2 Gen2x1 (Type-A)1 x VGA1 x COM2 x RJ451 x MLAN3 x Audio jacks1 x ID button with LED |
| onboard-usb |
1 x USB 3.2 Gen1 x2 header |
| other-connectors |
1 x 24-pin ATX main power connector2 x 8-pin ATX 12V power connectors1 x CPU fan header6 x System fan headers1 x Front audio header2 x M.2 slots2 x SlimSAS connectors1 x VROC connector1 x Front panel header1 x Backplane board header1 x PMBus header1 x IPMB header1 x TPM header |
| form-factor |
CEB |
| dimensions-w-x-l |
12.0" x 10.5" |
| package-contents |
1 x MW83-RP01 x I/O shield1 x Quick start guide*1 x W-3500/3400 (E1A) carrier1 x SlimSAS to 4 x SATA 6Gb/s cable (600mm)*Carriers for Intel Xeon W-2500/2400 Processors are not included. |
| first-listed-on-newegg |
November 09 ,2023 |
